B&K Ref. 30 Problem

I mistakenly posted this under Misc. as a Ref. 20 problem so I'm re-posting under Home Theater.

I recently purchased this processor to replace a Lexicon processor that died. It may be an interim step while I decide if I want to invest in a new processor with HDMI. I do not run a center channel and have the B&K setup for 2 front and 2 surround. My problem is that I’m unable to get center channel information through the front L&R speakers using the digital outputs from either my Fios box or BD player. My BD has 5.1 out so I setup the B&K that way playing movies and center channel information comes through loud and clear. My Fios box does not have 5.1 so I’m forced to use the audio digital outs. Video for both Fios and BD is through HDMI direct to the TV. I never had a problem setting up a phantom center with my other processor(s) and did not change any settings on the Fios box or BD digital outs while setting up the B&K, so it appears to be something in the B&K.

Can anyone suggest a troubleshooting procedure or a particular setting for the B&K to correct the problem?
I just sent a reply for your Ref20 post. What I said was to try setting your center channel to 'No' to cause the Ref30 to generate a phantom center. Good luck.
Thanks Noble. Center is already set to "None" in an attempt to generate the phantom center. That's my dilemma. Still will not process the center information to the Front left and right speakers.

Sorry, should have read your post more closely, thought I was onto something. You have the bluray hooked up to the 5.1 inputs and the Fios box hooked to the digital input and you're having the same problem through both input types.
I'm stumped right now but I'll reply again if I think of anything. Thanks.
intuitively, it sounds like a setup issue, but:
1. with the digital connections, are you currently getting sound through your 2 surrounds or only your fronts?
2. exactly what audio mode are you using on your b&k (surround, thx,dvd audio?).
1. try connecting only 2ch rca analog from your bd/fios to your b&k analog inputs and playing in surround mode. do you get center info?
3. are you connecting the fios to the tv input on your b&k? the manual says "if you have source with only digital output don't connect it to tv"
4. are you having the same issue with digital coax as you are with digital optical?
5. have you tried disconnecting the hdmi cable from your bd/fios and playing audio only? what happens?
6. in your current set up, have you tried connecting one of your speakers to the center? what happens?
Noble, thanks again. My only problem is through the digital inputs. When I hook-up BD through the analog inputs, the 5.1 center channel information comes through the front L&R speakers loud and clear.

Loomis, you mention somethings I haven't thought to try. Hopefully I'll have a chance later this weekend to experiment and report my findings. Thanks very much for you help so far.
Loomis, here goes:

1. Get sound through front and surrounds both;
2. For Fios through digital using surround. For BD through 5.1 analog using dvd audio;
3. No but does not matter what input I connect to DVD, TV, SAT, etc., I still do not get center information through front L&R;
4. Yes, same issue with either coax or optical;
5. Not sure why this would matter but I tried it. No difference. No center channel info. to L&R fronts with hdmi plugged in or not plugged in; and
6. Finally, and I had high hopes for this one. Plugged rear speaker into center channel and got center channel audio loud and clear.

This is very perplexing.


Loomis, also:

2.1 Get center channel info. through front L&R this way. Also get center channel info. through front L&R when I listen through digital connection in stereo.
so you've set the b&k to "no center" and, when your sources are connected to the analogue ins (whether rca or 5.1)the b&k is acting correctly. however, when you're sources are connected digitally, for whatever reason your b&k is reading "no center" incorrectly and is sending the center info to the center channel (except digital connection in stereo mode, when the b&k acts correctly). ergo, it seems that your b&k processor is malfunctioning when it's in "surround mode"--this is evidenced by the fact that even tho you've set it to "no center" when you connected a center speaker the b&k actually sent the center info to the center speaker.
if you'd humor me, please:
try using your current setup w/digital connection in "thx" mode--do you still get no center info?
if our conclusion is right, two possible workarounds:
1. get a center channel, since the b&k seems to be sending center info there even though you've setup for no center; or
2. use the analog inputs instead of the digital ones since these seem to work correctly; you could add a dac to your sources to improve the sound.
interesting problem--please report back
Loomis, I'll send you a case of Good Humor's (choice of flavor) if you solve this for me :-). Your understanding of my problem is exactly right. Also, already tried "thx", still no center info:.

Regarding the workarounds:

Already thought about adding a center speaker, but really don't want to. No room; would need an additional amp; and would give the wife one more thing to bitch about; and

Already doing #2 in a sense by playing in stereo instead of surround through digital input.

I normally don't listen to TV (Fios) through my HT set-up since it is a combo 2ch/tube system. So its not the end of the world if I can't figure this out. As an aside, what I just noticed yesterday when watching the football games is that when the commercials come-on, typically the center channel information is there in surround. When the announcers come back on, center channel info. disappears to the point the dialogue is VERY muted. Again this is when playing through digital/surround. Dialogue seems fine through digital/stereo (or mono).
i think what you're getting in surround mode isn't center info, but the portion of the dialogue that gets normally summed to the L/R in the course of digital processing--the fact that it's much louder during the commercials is attributable to the fact that volume during commercials is normally amped up to obnoxiously deafening levels.
ergo, the b&k's processor is deranged--i wouldn't invest in fixing it, since it's easy to find a new (used) unit for a couple hundo. it does sound like you could connect with just rca and still use surround mode. sorry i couldn't be more helpful.
Marco1, Have you set the Favorite Speakers to 4 (page 40 of the Owner’s Manual)?
Imhififan, yes I have.

Thanks again Loomis.
